0x9 Long Connections (Sockets)

Definition

ROOM: An independent collaborative workspace (room).

RESOURCE: A data resource unit that participates in collaboration in ROOM, which can be a datasheet, widget, etc. Relationship:

Each ROOM is unique and includes one or more collaborators and RESOURCEs.
The same RESOURCE can be in different ROOMs, and the relationship between the two is many-to-many.
Users can open multiple clients and be in multiple ROOMs.

Message Types

Client Actively Pushes

User establishes a collaborative ROOM long connection channel. (WATCH_ROOM)
Each datasheet (form/dashboard, etc.) opened by the user can create an independent ROOM.
The ROOM identifier is a node ID or resource unit ID (such as: a separately opened widget).

Request message body structure:

{
    "roomId": string;
    "shareId": string;
}

Web Socket pushes events to Nest server to obtain collaborator information and the latest revision numbers of various resources within the ROOM.

Data structure returned to client:

{
    "collaborators": {
        "socketId": string;
        "createTime": number;
        "userId": string;
        "avatar": string;
        "userName" : string;
        "memberName": string;
    }[];
    "resourceRevisions":{
        "resourceId": string;
        "revision": number;
    }[]
}

Data structure broadcasted to collaborators: (ACTIVATE_COLLABORATOR)

{
        "socketId": string;
        "createTime": number;
        "userId": string;
        "avatar": string;
        "userName": string;
        "memberName": string;
}

User leaves collaboration room (LEAVE_ROOM):
```
{
        "roomId": string;
}
```

Data structure broadcasted to collaborators: (DEACTIVATE_COLLABORATOR)

{
        "roomId": string;
        "socketId": string;
}

ROOM sends changesets (CLIENT_ROOM_CHANGE):

{
    "roomId": string;
    "changesets": ILocalChangeset[];
}

interface ILocalChangeset {
    "messageId": string;
    "baseRevision": number;
    "resourceId": string;
    "resourceType": ResourceType;
    "operations": IOperation[];
}

Web Socket pushes evnets to Nest server
Nest server: Process changesets transactionally

Data structure returned to Socket server:

{
        "changeset": IRemoteChangeset;
        "roomIds": string[];
}[]

Every Changeset of a RESOURCE is broadcasted to all ROOMs that contain that RESOURCE.

Data structure broadcasted to collaborators (SERVER_ROOM_CHANGE):

{
        "success": boolean;
        "code": number;
        "message": string;
        "data": IRemoteChangeset[];
}

collaborate the cursor (ENGAGEMENT_CURSOR)

Send data about the activated cell:

{
        "datasheetId": string;
        "viewId": string;
        "fieldId": string;
        "recordId": string;
        "time": number;
}

Web Socket broadcasts to collaborators (ENGAGEMENT_CURSOR), the data structure is the same as above ENGAGEMENT_CURSOR.

Client Passively Receives

A new collaborator enters the room. (ACTIVATE_COLLABORATOR)
A collaborator leaves the room. (DEACTIVATE_COLLABORATOR)
Collaborative changesets in the room. (SERVER_ROOM_CHANGE)
The collaborative cursor of other collaborators in the room. (ENGAGEMENT_CURSOR)

ROOM-RESOURCE two-way relation

Nest server is responsible for maintaining ROOM-RESOURCE two-way relations.

Maintain update points:

Load resource data
Room Changeset involving the addition or deletion of resources.
